› CPU: NXP AMR Cortex A53 Quad core, 1,8 GHz
› LED colors
› Touchless fingerprint sensor: QR code scanning capability (1)
› Contactless reader options: Prox, iCIass, MIFARE/DESFire, SEOS, HID Prox mobile access
› Tamper switches
› Internal storage capacity: 16 GB Flash, 2GB RAM
• 10,000 user records (2* 4 fingers each) for 1:N identification
• 250,000 IDs in authorized user list
• 1 Million transaction logs
› Network/Communication: Ethernet, RS485, RS422 (2) › • WI-FI option
› Inputs/outputs: Wiegand In & Out (customizable up to 512 bits), OSDP, Door relay, 3 GPI (including door monitoring), 3 GPO
› Power supply: 12 to 24 V DC (2.5A min @12V)
› Power over Ethernet with PoE+ switches
› Operating conditions:
• Temperature: -10°C to 55°C (14°F to 131°F)
• Humidity: 10%>80% (non condensing)
› Ingress protection: IP65 (3)
› HxWxD: 250*152*216 mm (9.9*6*8.5 in)
› Weight: 2.2 kg (4.85 lb.)
› EMC/Safety standards: CE, CB, FCC
› RoHS, REACh, and WEEE compliant
