› CPU: Nvidia AMR Cortex A15 Quad core, 2,1 GHz
› 4.3’’ WVGA color capacitive touchscreen
› Loudspeaker & microphone Intercom function
› Audio & video player
› Touchless fingerprint sensor: Hand presence detection QR code scanning capability (1)
› Contactless reader options: Prox, iCIass, MIFARE/DESFire, SEOS, HID mobile access
› Tamper switches
› Internal storage capacity:
16 GB Flash, 2GB RAM
• 40,000 user records (2* 4 fingers each) for 1:N identification, extendable to 100,000 with license
• 250,000 IDs in authorized user list
• 1 Million transaction logs
› Network/Communication: Ethernet, RS485, RS422, USB (2) › • WI-FI and 4G options
› Inputs/outputs: Wiegand In & Out (customizable up to 512 bits), OSDP, Door relay, 3 GPI (including door monitoring), 3 GPO
› Power supply:
12 to 24 V DC (2.5A min @12V)
Power over Ethernet with PoE+ switches
› Operating conditions:
Temperature: -10°C to 55°C (14°F to 131°F)
Humidity: 10%>80% (non condensing)
› Ingress protection: IP65 (3)
› HxWxD: 250*152*216 mm (9.9*6*8.5 in)
› Weight: 2.2 kg (4.85 lb.)
› EMC/Safety standards: CE, CB, FCC
› RoHS, REACh, and WEEE compliant
› CPU: Nvidia AMR Cortex A15 Quad core, 2,1 GHz
› 4.3’’ WVGA color capacitive touchscreen
› Loudspeaker & microphone Intercom function
› Audio & video player
› Touchless fingerprint sensor: Hand presence detection QR code scanning capability (1)
› Contactless reader options: Prox, iCIass, MIFARE/DESFire, SEOS, HID mobile access
› Tamper switches
› Internal storage capacity: 16 GB Flash, 2GB RAM
• 40,000 user records (2* 4 fingers each) for 1:N identification, extendable to 100,000 with license
• 250,000 IDs in authorized user list
• 1 Million transaction logs
› Network/Communication: Ethernet, RS485, RS422, USB (2) › • WI-FI and 4G options
› Inputs/outputs: Wiegand In & Out (customizable up to 512 bits), OSDP, Door relay, 3 GPI (including door monitoring), 3 GPO
› Power supply:
12 to 24 V DC (2.5A min @12V)
Power over Ethernet with PoE+ switches
› Operating conditions:
Temperature: -10°C to 55°C (14°F to 131°F)
› Humidity: 10%>80% (non condensing)
› Ingress protection: IP65 (3)
› HxWxD: 250*152*216 mm (9.9*6*8.5 in)
› Weight: 2.2 kg (4.85 lb.)
› EMC/Safety standards: CE, CB, FCC
› RoHS, REACh, and WEEE compliant
