- CPU: IMX8+ 4 core A53
• 1 cortex M7 + CNN capabilities
- 4.3’’ WVGA color capacitive touchscreen
- Touchless fingerprint sensor
Hand presence detection QR code scanning capability3
Contactless reader options:
- Standard : MiFare/DESFire Options5: HID iClass, SEOS cards, HID mobile credentials, Apple Wallet
- Tamper switches
- Internal storage capacity: 16GB Flash, 4GB RAM
• 40,000 user records (2*4 fingers each for 1:N identification, extendable to 100,000 with licenses
• 250,000 IDs in authorized user list
• 1 Million transaction logs
- Network/Communication: Ethernet, RS485, USB
- Inputs/outputs: Wiegand In & Out (customizable up to 512 bits), OSDP, Door Relay, 3 GPI (including Door monitoring), 3 GPO
- Power supply: 12 to 24 V DC (2.5A min @12V)
• Power over Ethernet with PoE+ switches
- Operating conditions:
• Temperature: -10°C to 55°C (14°F to 131°F)
• Humidity: 10% to 80% (non condensing) Ingress protection: IP65(2)
- HxWxD = 250*152*216 mm (9.9*6*8.5 in.)
- Weight: 2.2 kg (4.85 lb.)
- EMC/Safety standards: CE, CB, FCC RoHS, REACh and WEEE compliant
