› CPU: Nvidia ARM Cortex-A15 Quad-Core 2.1GHz
› 7” WVGA color capacitive touchscreen › Loudspeaker & microphone › Audio & video player
› Touchless face sensor: Visible light camera (2D) Infrared camera (2D) 3D camera
› Contactless reader options: HID Prox, iCIass, MIFARE/DESFire Natively supports PIN code
› Tamper switches
› Internal storage capacity: 20,000 user records extendable up to 40,000 with license 250,000 IDs in authorized user list 1 Million transaction logs
› Network/Communication: Ethernet, RS485, RS422
› Inputs/outputs: Wiegand In & Out (customizable up to 512 bits), OSDP, Door relay, 3 GPI (including door monitoring), 3 GPO
› Power supply: 12 to 24 V DC (3A min @12V)
› Operating conditions:
Temperature: -10°C to 45°C (14°F to 113°F)
Humidity: 10%>80% (non condensing)
› Ingress protection: IP65
› HxWxD: 325x143x110 mm/12.8x5.6x4.3 in
› Weight: 2,1kg/4.63lbs
› EMC/Safety standards: CE, CB, FCC
› RoHS, REACH, California, Proposition 65 and WEEE compliant
