› CPU: Multi-Core 1.8GHz + NPU
› 5” WVGA color capacitive touchscreen
› Face acquisition: 2 x 2 MP visible/IR, 3D stereovision
› Illumination: white and infrared LEDs › Proximity sensor: 60GHz radar sensor › Sound: buzzer
› Face performances
Intention area 0.3 to 1.0 m (adjustable) Field of view (H x V): 55° x 90°
User height from 1.2 to 2.0 m Matching speed < 1s
Flow rate: 30 users per minute Active Presentation Attack Detection Compatible with masks
› Contactless reader options:
MIFARE/DESFire, HID iCIass, SEOS Natively supports PIN codes
QR code scanning capability
› Internal storage capacity:
Flash 16Gb and RAM 4Gb
Up to 10,000 users in the database 250,000 IDs in authorized user list 1 million transaction logs
› Security
Secure booting and authenticity check Cryptographic technologies to secure sensitive data
Data protection with AES-256 database encryption
Network communication encryption with TLS 1.2 Network authentication with 802.1.X
OSDP secure channel Tamper switches
› Network/communication: Ethernet, RS485
› Inputs/outputs:
Wiegand in and out, OSDP, door relay,
three GPI (including door monitoring), three GPO
› Power supply:
12 to 24 V DC (2,5A min @12V)
Power over ethernet with PoE+ switches
› Accessories: Available on request
› Operating conditions: Temperature: -10°C to 45°C (14°F to 113°F)
Humidity: 10%>80% (noncondensing)
› Ingress protection: IP65
› HxWxD: 21 x 10.2 x 3.5cm 8.2” x 4’’ x 1.4”
› Weight: 0.8kg
› EMC/Safety standards: CE, CB, FCC
› RoHS, REACH, California Proposition 65 and WEEE compliant
› Environmental product declaration available on request
› Made in France
