| CAMERA | |
| Sensor | 1/3” Progressive Scan CMOS |
| Min. illumination | Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
| Focal length | 2.8 - 12 mm motorized lens @F1.6 |
| Focus | Auto |
| Angle of view | Horizontal FOV: 95.8° to 29.2° Vertical FOV: 50.6° to 29.2° Diagonal FOV: 114.6° to 33.4° |
| Lens mount | Φ14 |
| Shutter time | 1/3 s ~ 1/100,000 s |
| Slow shutter | Yes |
| Day/Night | IR cut filter with auto switch |
| Wide Dynamic Range | 120 dB WDR |
| Image usability | BLC/HLC/3D DNR |
| IR Distance | 60 m |
| DORI distances | Detect: 64 m to 200 m Observe: 25.4 m to 79.4 m Recognize: 12.8 m to 40 m Identify: 6.4 m to 20 m |
| VIDEO | |
| Max. resolution | 2688 × 1520 |
| Frame rate | Main Stream:50Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)60Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)Sub-Stream:50Hz: 25 fps (640 × 480, 640 × 360)60Hz: 30 fps (640 × 480, 640 × 360)Third Stream:50Hz: 25 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)60Hz: 30 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) |
| Video compression | H.265 Ultra/H.265/H.264 Ultra/H.264/MJPEG |
| Video bit rate | 32 Kbps - 8 Mbps |
| ROI | 1 fixed region for main stream and sub-stream |
| Image settings | Rotate, mirror, privacy masks, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
| Smart Features | Line crossing detection, intrusion detection. Supports human and vehicle targets classification.Face detection |
| AUDIO/ALARM | |
| Audio I/O | 1 input (line in), two-core terminal block, max. input amplitude: 3.3 vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium;1 output (line out), two-core terminal block, max. output amplitude: 3.3 vpp, output impedance: 100 Ω, interface type: non-equilibrium |
| Audio compression | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC |
| Audio bit rate | 64Kbps(G.711ulaw/G.711alaw)/16Kbps(G.722.1)/16Kbps(G.726)/16Kbps- 64Kbps(AAC)/32-192Kbps(MP2L2)/8-320Kbps(MP3) |
| Alarm I/O | 1 input, 1 output (max. 12 VDC, 30 mA) |
| Alarm trigger | Motion detection (human and vehicle), video tampering alarm, exception, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
| NETWORK | |
| Local storage | Built-in Micro SD / SDHC / SDXC card slot, up to 256 GB |
| Network storage | NAS (Support NFS,SMB/CIFS) |
| Communication interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
| BNC | BNC connector integrated |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE |
| Security | One-key reset, anti-flicker, heartbeat, password reset via e-mail, pixel counter |
| Compliance | ONVIF (Profile S, Profile G), ISAPI |
| GENERAL | |
| Power supply | 12 VDC ± 25%, Ø5.5 mm coaxial power plugPoE: 802.3at, Class 4 |
| Power consumption | 12 VDC, 1.08 A, max. 13 WPoE: (802.3at, 42.5 V to 57 V), 0.36 A to 0.27 A, max. 15 W |
| Operating conditions | -30 °C to 60 °C (-22°F to 140 °F) Humidity: 95% or less (non-condensing) |
| Protection level | IP67 |
| Impact protection | IK10 |
| Material | Aluminum alloy body |
| Dimensions | 308.5 × 97.9 × 93 mm (12.2" × 3.9" × 3.7") |
| Weight | Approx. 1390 g (3.1 lb.) |
