| CAMERA | |
| Sensor | 1/2.8” Progressive Scan CMOS |
| Min. illumination | Color: 0.0025 Lux @ (F1.2, AGC ON) |
| Shutter time | 1/3 s to 1/100,000 s |
| Slow shutter | Yes |
| Lens | 3.7 mm |
| Angle of view | Horizontal FOV 75.5°, vertical FOV 41.6°, diagonal FOV 87.3° |
| Day/Night | Day, Night, Auto, Schedule |
| Privacy mask | Support |
| Wide Dynamic Range | 120 dB WDR |
| Image usability | BLC, HLC, defog, 3D DNR |
| VIDEO | |
| Max. resolution | 1920 × 1080 |
| Frame rate | Main Stream:50Hz: 50fps (1920 × 1080, 1280 × 720)60Hz: 60fps (1920 × 1080, 1280 × 720)Sub Stream:50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)Third Stream:50Hz: 1fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360, 320 × 240)60Hz: 1fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360, 320 × 240) |
| Video compression | H.265, H.264, MJPEG |
| ROI | Support 1 fixed region for main stream |
| Image settings | Saturation, brightness, contrast, and sharpness adjustable by client software or webbrowser |
| People counting | Intrusion detection, line crossing detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, audio exception detection, defocus detection, scene change detection. |
| AUDIO / ALARM | |
| Audio I/O | 1 input (line in), 1 output (line out) |
| Alarm trigger | Motion detection, video tampering alarm, IP address conflict, illegal login |
| NETWORK | |
| Network storage | NAS (Support NFS, SMB/CIFS) |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| Communication interface | 1 RJ45 10M/100M Ethernet port |
| Compliance | ONVIF (Profile S, Profile G), ISAPI |
| Simultaneous Live View | Up to 6 channels |
| User/Host | Up to 32 users3 levels: Administrator, Operator and User |
| Security measures | One-key reset, heartbeat, mirror, password protection, privacy mask, rotate, watermark, IP address filter |
| GENERAL | |
| Power supply and consumption | 12 VDC ± 20%, 0.13A, max. 1.5W. Φ 5.5 mm coaxial plug power |
| Operating conditions | -30 °C to 60 °C (-22°F to 140°F) Humidity 95% or less (non-condensing) |
| Dimensions | 31.5 mm × 31.5 mm × 39.7 mm (1.2" × 1.2" × 1.6") |
| Weight | Approx. 93 g (0.2 lb.) |
