| CAMERA | |
| Sensor | 1/2.7” Progressive Scan CMOS |
| Min. illumination | Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
| Focal length | 4mm |
| Angle of view | Horizontal FOV: 91.5° Vertical FOV: 46.1° Diagonal FOV: 109.8 |
| Lens mount | M12 |
| Shutter time | 1/3 s ~ 1/100,000 s |
| Slow shutter | Yes |
| Day/Night | IR cut filter with auto switch |
| Wide Dynamic Range | 120 dB WDR |
| Image usability | 3D DNR/BLC |
| Angle Adjustment | Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
| IR Distance | 30 m |
| VIDEO | |
| Max. resolution | 1920 × 1080 |
| Frame rate | Main stream:50 Hz: 25 fps (1920 × 1080, 1280 × 720)60 Hz: 30 fps (1920 × 1080, 1280 × 720)Sub stream:50Hz: 25 fps (640 × 480, 640 × 360)60Hz: 30 fps (640 × 480, 640 × 360) |
| Video compression | H.265 Ultra / H.265 / H.264 Ultra / H.264 / MJPEG |
| Video bit rate | 32 Kbps - 8 Mbps |
| Video Streaming | Dual stream |
| Image settings | Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser |
| Region of Interest | Support 1 fixed region for main stream |
| Smart Features | Line crossing detection, intrusion detection |
| AUDIO/ALARM | |
| Alarm trigger | Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD error, HDD full |
| NETWORK | |
| Local storage | Built-in Micro SD/SDHC/SDXC slot, up to 256 GB |
| Network storage | NAS (Support NFS,SMB/CIFS) |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS |
| Communication interface | 1 RJ45 10 M / 100 M self-adaptive Ethernet port |
| Simultaneous Live View | Up to 6 channels |
| Users | Up to 32 users3 levels: Administrator, Operator and User |
| Security | One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark |
| Compliance | ONVIF (Profile S, Profile G), ISAPI |
| GENERAL | |
| Power supply | 12 V DC ± 25%PoE (802.3af class 3) |
| Power consumption | 12 VDC, 0.4 A, max. 5 WPoE (802.3af, 36 to 57 V), 0.2 A to 0.15 A, max. 6.5 W |
| Operating conditions | -30 °C to 60 °C (-22 °F to 140 °F) Humidity: 95% or less (non-condensing) |
| Protection level | IP67 |
| Material | Front Cover: Plastic Back cover: Metal |
| Dimensions | 69.7 mm × 67.9 mm x 171.4 mm (2.7" × 2.7" × 6.7") |
| Weight | 350 g (0.8 lb) |
